Meraki MX Captive Portal

How It Works

Spotipo integrates with Meraki MX security appliances through custom RADIUS authentication, enabling captive portal functionality on wired VLANs without additional hardware or firmware modifications.

No firmware changes required. Leverages Meraki MX's built-in RADIUS support for seamless captive portal deployment on wired VLAN networks.

VLAN-based authentication. Deploy captive portal on specific VLANs for secure guest access while maintaining separation from internal corporate networks.

Custom RADIUS integration. Configure Spotipo as your RADIUS authentication and accounting server for complete control over guest access and usage tracking.

Cloud-managed simplicity. Configure everything through Meraki Dashboard without touching physical hardware or complex command-line interfaces.

Walled garden control. Pre-configured access lists for Spotipo infrastructure, Stripe payments, and social authentication ensure seamless guest experiences.

Multi-site scalability. Manage captive portal settings across multiple Meraki MX appliances from a centralized Spotipo dashboard.

1. Create Meraki MX Site

Generate your Meraki MX configuration in Spotipo dashboard, receiving RADIUS server credentials and custom splash page URL automatically.

2. Configure VLAN Access Control

Set up VLAN-specific access control in Meraki Dashboard with custom-hosted splash page and RADIUS authentication method.

3. Add RADIUS Servers

Configure primary and secondary RADIUS authentication servers (port 1812) and accounting servers (port 1813) using Spotipo-generated credentials.

4. Configure Walled Garden

Add Spotipo infrastructure domains and optional payment/social login services to walled garden for uninterrupted authentication flow.

Ideal for Meraki MX Deployments

Corporate Guest Access - Secure VLAN-based guest WiFi for office visitors and contractors
Multi-Tenant Buildings - Property managers offering monetized WiFi on isolated VLANs per tenant
Branch Office Networks - Distributed enterprises standardizing guest access across Meraki MX locations
Secure Facilities - Organizations requiring network segregation with professional guest WiFi experience

Need More Help with Meraki MX?

Check out our complete setup guide:

• How to Configure Meraki MX with Spotipo - Complete VLAN configuration walkthrough
